Kerman, CA · Fresno County
Plot Plan Application
This application and drawing guide helps property owners submit plot plan details for residential additions or alterations that change a site.
What this form is
The Plot Plan Application collects property and site information for city planning and engineering review, including lot dimensions, structures, setbacks, fences, landscaping, and utility details. A plot plan is required for a residential addition or alteration involving a site change and should accompany the Building Permit Application. The guide also lists required plan information and says to draw plans to scale with enough clarity to show regulatory conformance.
Who needs it
Property owners applying for a residential addition or alteration involving a site change should include a plot plan with their Building Permit Application.
How to submit it
Submit the plot plan as part of your Building Permit Application to the Building Division at [email protected].
About notarization
This document is completed without a notary; it names no sworn attachment or notarized step, and the applicant completes the information and dates the plan.
How to submit this form
- 1
Download The Application
Download the Plot Plan Application and example.
- 2
Complete The Plot Plan
Provide the required property and project information and draw the plan to scale with enough clarity to show applicable conditions.
- 3
Gather Required Details
Show buildings, yards, walls, fences, landscaping, setbacks, lot dimensions, and the other information listed in the guide.
- 4
Submit With Your Building Permit Application
Send the plot plan as part of your Building Permit Application to the Building Division at [email protected].
Frequently asked questions
- Do I need a notary for the Plot Plan Application?
- No. The document does not require notarization or identify a sworn attachment; complete the requested information and date the plan.
- Who needs to submit a plot plan?
- A plot plan is required for a residential addition or alteration involving a change to the site and should be submitted with the Building Permit Application.
- What information should the plot plan show?
- The guide lists owner and property details, project description, lot dimensions and coverage, buildings, yards, walls, fences, landscaping, setbacks, and legal description.
- How do I submit the Plot Plan Application?
- Submit the plot plan as part of your Building Permit Application to the Building Division at [email protected].
